The Wacker Neuson Elbow Fitting is a genuine OEM component designed for the RD7 and RD10 series double drum rollers, including models RD7Yehf HRC, RD7H, RD7Heh, RD7Yeh LRC, RD7Yeh HRC, RD7Hf. As a genuine Wacker Neuson part, the is manufactured to the same specifications as the original component installed at the factory, ensuring a direct, no-guesswork replacement. This elbow fitting slots into the hydraulic or fluid line circuit exactly as the original, maintaining correct fluid flow direction and connection integrity throughout the system.
Key Features
- Genuine OEM Construction — Manufactured by Wacker Neuson to match the original fitting geometry, thread spec, and material grade — ensuring proper sealing under operating pressure without adaptation.
- Direct-Connect Replacement — Threaded to the same specification as the original, this fitting connects directly into the existing port without the need for adapters or rework.
- Broad RD7 and RD10 Series Compatibility — Verified fitment across multiple RD7 variants (HRC, LRC, H, Heh, Af, Hfb configurations) and the RD10Yehf LRC, covering a wide range of Wacker Neuson double drum roller models.
- Maintains Fluid Circuit Integrity — A correctly functioning elbow fitting ensures fluid is routed at the correct angle and flow rate; a cracked or leaking fitting can cause pressure loss, fluid contamination, or system failure.
- Leak-Free Fluid Routing — Precision-machined threads and consistent material tolerances reduce the risk of fitting failure, seepage, or connection loosening under vibration-heavy roller operation.
An elbow fitting is a directional connector used within hydraulic or fluid line systems to route tubing or hose at a fixed angle — typically 45° or 90° — where a straight fitting would not fit the available space or would create excessive line stress. In a compaction roller like the RD7 or RD10 series, these fittings are critical to maintaining correct fluid routing between components such as the hydraulic drive circuit, water sprinkler system, or engine cooling lines. When an elbow fitting cracks, strips, or develops a leak, it can cause fluid loss, pressure drops, or contamination that disrupts machine operation and leads to more extensive damage if left unaddressed.
Part Details
| Part Number | 5100006531 |
|---|---|
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Elbow Fitting |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| RD7Yehf HRC | RD7Yehf HRC | 5100006337, 5100006341 |
| RD7H | RD7H | 5100006333 |
| RD7Heh | RD7Heh | 5100006334 |
| RD7Yeh LRC | RD7Yeh LRC | 5100006335 |
| RD7Yeh HRC | RD7Yeh HRC | 5100006336, 5100006467 |
| RD7Hf | RD7Hf | 5100006338 |
| RD7Hehf | RD7Hehf | 5100006339 |
| RD7Yehf LRC | RD7Yehf LRC | 5100006340 |
| RD7Af HRC | RD7Af HRC | 5100006342 |
| RD7Hfb | RD7Hfb | 5100006343 |
| RD7Hehfb | RD7Hehfb | 5100006344 |
| RD7Yehfb LRC | RD7Yehfb LRC | 5100006345 |
| RD7Yehfb HRC | RD7Yehfb HRC | 5100006346 |
| RD7Afb HRC | RD7Afb HRC | 5100006347 |
| RD10Yehf LRC | RD10Yehf LRC | 5100070502 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
