The Wacker Neuson Screw Connection M20x1,5 is a genuine OEM component designed for the IRFU, IRSE-FU, FUflex, ARFU, and IEC series internal concrete vibrators. Sourced directly from Wacker Neuson, this part meets the exact dimensional and material specifications of the original, ensuring a correct and secure fit at the connection point. It is compatible across a broad range of models including IRFU30, IRFU38, IRFU45, IRFU58, and IRFU65 variants in both 230V and 120V configurations, as well as IRSE-FU and ARFU converter-equipped units. Keeping this connection fitting in good condition is essential to maintaining the integrity of the vibrator assembly during operation.
Key Features
- Genuine OEM Thread Integrity — Manufactured to Wacker Neuson's exact M20x1.5 thread specification, ensuring full engagement and a leak-free, play-free connection at the vibrator housing interface.
- Direct Bolt-In Replacement — Threads directly into the original port using the M20x1.5 fine-thread pitch — no re-tapping, adapters, or rework needed at installation.
- Broad Series Compatibility — Fits IRFU, IRSE-FU, FUflex4, ARFU, and IEC series internal vibrators across 30mm, 38mm, 45mm, 58mm, and 65mm head diameters in both 230V and 120V variants.
- Maintains Vibrator Output Consistency — A correctly seated screw connection keeps the internal vibrator assembly properly sealed and aligned, preserving the full compaction force delivered to the concrete.
- Electrical Safety Compliance — As a structural connection component on high-frequency electrical vibrator equipment, using the correct OEM fitting helps maintain the enclosure rating and safe operation of the converter unit.
A screw connection on a concrete internal vibrator serves as a threaded coupling that joins sections of the vibrator assembly — typically linking the flexible drive shaft housing, vibrator head, or converter connection — and keeps the unit mechanically secure during use. If this fitting becomes damaged, cross-threaded, or worn, the joint can loosen under the high-frequency vibration loads the equipment generates, leading to misalignment, moisture ingress, or complete separation of the assembly. Replacing a failed or degraded screw connection with the correct OEM part restores the structural integrity of the vibrator and ensures the machine performs safely and consistently on the job.
Part Details
| Part Number | 5100030434 |
|---|---|
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Screw Connection M20x1,5 |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| IRFU45/230/5 | IRFU45/230/5 | 5000610024 |
| IRFU38/230/5 | IRFU38/230/5 | 5000610025 |
| IRFU65/230/5 | IRFU65/230/5 | 5000610104 |
| IRFU38/230/5 CH | IRFU38/230/5 CH | 5000610245 |
| IRFU38/230/5GV | IRFU38/230/5GV | 5000610247 |
| IRFU45/230/5 CH | IRFU45/230/5 CH | 5000610253 |
| IRFU45/230/5GV | IRFU45/230/5GV | 5000610255 |
| IRSE-FU45/230 | IRSE-FU45/230 | 5000610256 |
| IRFU65/230/5 CH | IRFU65/230/5 CH | 5000610290 |
| IRFU30/230/5 | IRFU30/230/5 | 5000008959 |
| IRFU58/230/5 | IRFU58/230/5 | 5000610007 |
| IRFU58/230/5 CH | IRFU58/230/5 CH | 5000610263 |
| IRFU58/230/5GV | IRFU58/230/5GV | 5000610265 |
| IRSE-FU58/230 | IRSE-FU58/230 | 5000610267 |
| IRFU30/230/5 CH | IRFU30/230/5 CH | 5000610278 |
| IRFU45/120/5 UK | IRFU45/120/5 UK | 5000610097 |
| IRFU38/120/5 UK | IRFU38/120/5 UK | 5000610099 |
| IRFU58/120/5 UK | IRFU58/120/5 UK | 5000610008 |
| IRFU30/120/5 UK | IRFU30/120/5 UK | 5000610101 |
| IRFU65/120/5 UK | IRFU65/120/5 UK | 5000610105 |
| External Vib. ARFU 36/6/230 | ARFU 36/6/230 | 5000610000 |
| IRFU65/230/10 | IRFU65/230/10 | 5100008878 |
| IRFU65/230/5GV | IRFU65/230/5GV | 5100015351 |
| FUflex4/230 | FUflex4/230 | 5100021653 |
| Int. Vib. w. Conv. IRSE-FU 38/230 | IRSE-FU 38/230 | 5000610249 |
| Int. Vib. w. Conv. IRSE-FU 38/230 Laser | IRSE-FU 38/230 Laser | 5000610250 |
| IRSE-FU 45/230/03 | IRSE-FU45/230 Laser | 5000610257, 5100019680 |
| Int. Vib. w. Conv. IRFU 57k/230 | IRFU 57k/230 | 5000610262 |
| IRSE-FU 57/230/03 | IRSE-FU 57/230 Laser | 5000610268 |
| Int. Vib. w. Conv. IRFU 30/230 GV | IRFU 30/230 GV | 5000610276 |
| Int. Vib. w. Conv. IRSE-FU 30/230 | IRSE-FU 30/230 | 5000610280 |
| Int. Vib. w. Conv. IRSE-FU 30/230 Laser | IRSE-FU 30/230 Laser | 5000610281 |
| Int. Vib. w. Conv. IRFU 65/230 GV | IRFU 65/230 GV | 5000610285 |
| ARFU26/6/120 US | ARFU26/6/120 US | 5100004244 |
| IRFU45/230/10 | IRFU45/230/10 | 5100008834 |
| IRFU58/230/10 | IRFU58/230/10 | 5100008835 |
| IRFU38/230/10 | IRFU38/230/10 | 5100008871 |
| IRFU30/230/10 | IRFU30/230/10 | 5100008877 |
| IRFU38/120/10 UK | IRFU38/120/10 UK | 5100008934 |
| IRFU45/120/10 UK | IRFU45/120/10 UK | 5100008935 |
| IRFU58/120/10 UK | IRFU58/120/10 UK | 5100008936 |
| IRSE-FU58/230Laser | IRSE-FU58/230Laser | 5100019681 |
| IRFU65/230/15 | IRFU65/230/15 | 5100040888 |
| ARFU 36/6/115/US EXT. VIBRATOR | ARFU 36/6/115 | 5000610002, 5000610003 |
| IRFU30 Internal Vibrator, 115V, 1.2", 5 Meter | IRFU30/120/5 US | 5000610102 |
| ARFU26/6/230 | ARFU26/6/230 | 5100004243 |
| ARFU26/6/115 | ARFU26/6/115 UK | 5100004245 |
| IRFU30/230/15 | IRFU30/230/15 | 5100040884 |
| IRFU38/230/15 | IRFU38/230/15 | 5100040885 |
| IRFU45/230/15 | IRFU45/230/15 | 5100040886 |
| IRFU58/230/15 | IRFU58/230/15 | 5100040887 |
| IRFU38/120/15 UK | IRFU38/120/15 UK | 5100040889 |
| IRFU45/120/15 UK | IRFU45/120/15 UK | 5100040890 |
| IRFU58/120/15 UK | IRFU58/120/15 UK | 5100040891 |
| IRFU65/120/15 UK | IRFU65/120/15 UK | 5100040892 |
| High frequency internal vibrator with integrated converter IRFU38/120 GV GB | IRFU 38/120 GV GB | 5000610246 |
| Int. Vib. w. Conv. IRSE-FU 38/120 GB | IRSE-FU 38/120 GB | 5000610251 |
| IRSEFU 38 | IRSE-FU 38/120 US | 5000610252 |
| High frequency internal vibrator with integrated converter IRFU45/120 GV GB | IRFU 45/120 GV GB | 5000610254 |
| Int. Vib. w. Conv. IRSE-FU 45/120 GB | IRSE-FU 45/120 GB | 5000610258 |
| IRSEFU 45 | IRSE-FU 45/120 US | 5000610261 |
| High frequency internal vibrator High frequency internal vibrator with integrated converter IRFU57/120/5r | IRFU 57/120 GV GB | 5000610264 |
| Int. Vib. w. Conv. IRSE-FU 57/120 GB | IRSE-FU 57/120 GB | 5000610271 |
| IRSEFU 57 | IRSE-FU 57/120 US | 5000610275 |
| High frequency internal vibrator with integrated converter IRFU30/120 GV GB | IRFU 30/120 GV GB | 5000610277 |
| Int. Vib. w. Conv. IRSE-FU 30/120 GB | IRSE-FU 30/120 GB | 5000610282 |
| IRSEFU 30 | IRSE-FU 30/120 US | 5000610283 |
| High frequency internal vibrator with integrated converter IRFU65/120 GV GB | IRFU 65/120 GV GB | 5000610286 |
| FUflex4/230 CH | FUflex4/230 CH | 5100025401 |
| FUflex4/120, 120 V | FUflex4/120 UK | 5100025402 |
| IEC45/120/3 US | IEC45/120/3 US | 5100036227 |
| IEC45/120/8 US | IEC45/120/8 US | 5100036228 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
