The Wacker Neuson 5100058578 is a genuine OEM Guiding Frame Complete designed for the APS and BPS series vibratory plate compactors. This structural assembly is a direct replacement sourced from Wacker Neuson, engineered to the same specifications as the original unit installed at the factory. Compatibility spans the full APS1030e, APS1030we, APS1135e, APS1135we, APS1340e, APS1340we, BPS1030A, BPS1030Aw, BPS1030B, BPS1030Bw, BPS1135A, BPS1135Aw, BPS1135B, BPS1135Bw, BPS1340A, BPS1340Aw, BPS1340Aws, BPS1340B, and BPS1340Bw lines, including US and EU regional variants. Verify your model number before ordering to confirm a correct match for your specific machine configuration.
Key Features
- Genuine OEM Structural Integrity — Manufactured by Wacker Neuson to the same material grade and dimensional tolerances as the original frame, ensuring the plate compactor's core geometry is maintained.
- Drop-In Replacement — Mounts using the original attachment points with no re-drilling or re-fabrication; the frame aligns directly with existing hardware and drive components.
- Broad APS and BPS Series Coverage — Fits the APS1030e, APS1135e, APS1340e and their "w" wet-surface variants, plus the full BPS1030, BPS1135, and BPS1340 A, B, and Aw/Bw lineup including US and EU regional builds.
- Preserves Plate Alignment and Vibration Transfer — A correctly fitted guiding frame keeps the exciter unit and compaction plate in proper alignment so vibration energy transfers efficiently into the ground surface rather than being lost through flex or misalignment.
- Battery and Gas Platform Compatible — Covers both the battery-powered APS series and gasoline-powered BPS series, making this a versatile stock item for fleet operators running mixed equipment.
The guiding frame is the primary load-bearing structural member that connects the handle assembly to the compaction plate and exciter unit on a vibratory plate compactor. It controls the geometry of the machine, keeps all major components in their correct relative positions, and absorbs the stresses generated during operation. When the guiding frame is cracked, bent, or worn at its mounting interfaces, the plate loses alignment, vibration energy becomes uneven, and operator control is compromised — leading to inconsistent compaction results and accelerated wear on surrounding components. Replacing a damaged frame with a genuine OEM unit restores the machine to its original operating geometry and protects the longevity of the exciter, plate, and handle vibration damping system.
Part Details
| Part Number | 5100058578 |
|---|---|
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Guiding Frame Complete |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| APS1030e | APS1030e | 5100059660 |
| APS1030we | APS1030we | 5100058917 |
| APS1135e | APS1135e | 5100059664 |
| APS1135we | APS1135we | 5100059661 |
| APS1340e | APS1340e | 5100060128 |
| APS1340we | APS1340we | 5100059663 |
| BPS1030A | BPS1030A | 5100059658 |
| BPS1030A US | BPS1030A US | 5100080504 |
| BPS1030A EU | BPS1030A EU | 5100084344 |
| BPS1030Aw | BPS1030Aw | 5100058916 |
| BPS1030Aw US | BPS1030Aw US | 5100080503 |
| BPS1030Aw EU | BPS1030Aw EU | 5100084343 |
| BPS1030B | BPS1030B | 5100065701 |
| BPS1030Bw | BPS1030Bw | 5100065702 |
| BPS1135A | BPS1135A | 5100059662 |
| BPS1135A US | BPS1135A US | 5100080506 |
| BPS1135A EU | BPS1135A EU | 5100084348 |
| BPS1135Aw | BPS1135Aw | 5100059657 |
| BPS1135Aw US | BPS1135Aw US | 5100080505 |
| BPS1135Aw EU | BPS1135Aw EU | 5100084347 |
| BPS1135B | BPS1135B | 5100065703 |
| BPS1135Bw | BPS1135Bw | 5100065704 |
| BPS1340A | BPS1340A | 5100059906 |
| BPS1340A US | BPS1340A US | 5100080508 |
| BPS1340A EU | BPS1340A EU | 5100084350 |
| BPS1340Aw | BPS1340Aw | 5100059659 |
| BPS1340Aw US | BPS1340Aw US | 5100080507 |
| BPS1340Aw EU | BPS1340Aw EU | 5100084349 |
| BPS1340Aws | BPS1340Aws | 5100060129, 5100067726 |
| BPS1340B | BPS1340B | 5100065705 |
| BPS1340Bw | BPS1340Bw | 5100063119, 5100065706 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
