The Wacker Neuson Stator is a genuine OEM component designed for the DPU5247, DPU5260, DPU5275, DPU6260, and DPU6275 series vibratory plates, including reversible and HATZ-powered variants. Sourced directly from Wacker Neuson, this stator is manufactured to the same specification as the original part installed at the factory, ensuring proper electrical output and compatibility within the machine's exciter system. It fits an extensive range of DPU models across multiple build variants, including Heh, Hehp, He, Hehcb+, Hehcpb+, and standard H configurations, making it the correct choice for a wide cross-section of the DPU5000 and DPU6000 plate compactor lineup.
Key Features
- Correct Electromagnetic Output: — Wound and calibrated to OEM specification, delivering the proper voltage and current characteristics required for stable exciter motor operation.
- Direct Drop-In Installation: — Matches the original mounting pattern and winding terminations, allowing straightforward replacement without modification to the housing or wiring harness.
- Broad DPU Series Coverage: — Compatible with DPU5247, DPU5260, DPU5275, DPU6260, and DPU6275 series vibratory plates across Heh, He, Hehcb+, Hehcpb+, Hehp, and H build variants.
- Restored Compaction Performance: — A failed or degraded stator causes the exciter motor to underperform or stop altogether, reducing compaction force; a fresh OEM stator restores full plate output.
- Electrical Safety Compliance: — As a genuine OEM winding, the 5100068939 meets the insulation class and load ratings specified for the machine, reducing the risk of electrical fault or motor damage caused by an out-of-spec replacement.
- Genuine Wacker Neuson Part: — Supplied as an authentic OEM component under part number 5100068939, ensuring traceability and fitment confidence across all listed DPU variants.
The stator is the stationary winding assembly within the exciter motor of a vibratory plate compactor. It generates a rotating magnetic field that drives the rotor, which in turn powers the eccentric weights responsible for producing the plate's compaction force. When the stator degrades — through insulation breakdown, winding failure, or heat damage — the motor loses torque or fails to start, and the plate loses its vibration output entirely. Replacing a worn stator with a correctly specified OEM unit restores the motor's magnetic efficiency and returns the machine to its rated compaction performance.
Part Details
| Part Number | 5100068939 |
|---|---|
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Stator |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| DPU6275Heh | DPU6275Heh | 5100058467 |
| DPU5260Heh | DPU5260Heh | 5100060825 |
| DPU5260He | DPU5260He | 5100076465 |
| DPU5260Hehp | DPU5260Hehp | 5100076466 |
| DPU5260Hehcb+ | DPU5260Hehcb+ | 5100076467 |
| DPU5260Hehcpb+ | DPU5260Hehcpb+ | 5100076468 |
| DPU6260Hehp | DPU6260Hehp | 5100076469 |
| DPU6260Hehcb+ | DPU6260Hehcb+ | 5100076470 |
| Vibration Plate DPU6275He | DPU6275He | 5100076471 |
| Vibration Plate DPU6275Hecb+ | DPU6275Hecb+ | 5100076472 |
| DPU6275Hehcb+ | DPU6275Hehcb+ | 5100076473 |
| Vibration Plate DPU5260Hep | DPU5260Hep | 5100077269 |
| DPU5275Heh | DPU5275Heh | 5100077270 |
| DPU5260H | DPU5260H | 5100077271 |
| Vibration Plate DPU5260Hehcpb+ LOXAM | DPU5260Hehcb+ LOXAM | 5100077272 |
| DPU5275Hehcb+ | DPU5275Hehcb+ | 5100077273 |
| Vibration Plate DPU5260Hp | DPU5260Hp | 5100077274 |
| DPU5260Hecpb+ | DPU5260Hecpb+ | 5100077275 |
| Vibration Plate DPU5275He | DPU5275He | 5100077276 |
| DPU5247Heh | DPU5247Heh | 5100077277 |
| Vibration Plate DPU5275H | DPU5275H | 5100077278 |
| DPU6260Heh | DPU6260Heh | 5100077280 |
| DPU6260Hehcpb+ | DPU6260Hehcpb+ | 5100077282 |
| Vibration Plate DPU6275H | DPU6275H | 5100077283 |
| DPU6260He | DPU6260He | 5100077284 |
| Vibration Plate DPU6260Hep | DPU6260Hep | 5100077285 |
| DPU6260Hecb+ | DPU6260Hecb+ | 5100077286 |
| Vibration Plate DPU6260Hecpb+ | DPU6260Hecpb+ | 5100077287 |
| Vibration Plate DPU6260H | DPU6260H | 5100077288 |
| Vibration Plate DPU6260Hp | DPU6260Hp | 5100077290 |
| DPU5545Heh US | DPU5545Heh US | 5100063122 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
