Wacker Neuson 5100075632 1/2-13x1-1/4 Hex Flange Screw Grade 5

The Wacker Neuson 1/2-13x1-1/4 Hex Flange Screw Grade 5 is a genuine OEM fastener designed for PDT3A, PDI3A, PDT2A, and PDI2A series diaphragm pumps. Sourced directly from Wacker Neuson, this is the same Grade 5 hex flange screw specified at the factory — not a generic substitute. Verified fitment spans the full range of PDT and PDI pump variants, so you can order with confidence that is the correct part for your machine.

Key Features

• Grade 5 Strength Rating — Medium-carbon steel construction meets the tensile and shear load requirements for structural fastener applications on Wacker Neuson pump assemblies.
• Integrated Flange Bearing Surface — The built-in flange distributes clamping load evenly without a separate washer, simplifying installation and ensuring consistent torque retention.
• Genuine OEM Part — Manufactured to Wacker Neuson's exact thread pitch, head geometry, and material specification for part number 5100075632.
• Broad Pump Series Coverage — Fits PDT3A, PDI3A, PDI3A(I), PDT2A, and PDI2A(I) diaphragm pump models from a single part number.
• Prevents Fastener Failure Under Vibration — A correctly torqued, properly spec'd hex flange screw maintains joint integrity in high-vibration pump environments; an undersized or mismatched fastener risks loosening and housing damage.

A hex flange screw combines a standard hex-head bolt with an integral load-spreading flange at the base of the head, acting like a built-in washer. In pump assemblies, these fasteners are used to secure housings, covers, and structural components that experience sustained vibration during operation. Using a fastener of the correct grade, thread size, and head style ensures the clamping force is distributed properly across the mating surface — a mismatched fastener can back out under load, allow housing flex, or cause thread damage that leads to more extensive repairs.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
