The Wacker Neuson 13507 is a genuine OEM Stud Bolt designed for a wide range of Wacker Neuson vibratory rammers and compaction equipment, including the BS30, BS45Y, BS45YA, BS52Y, BS60Y, BS65Y, and DS720 rammer series, as well as the DPS1850Y vibratory plate, DPU2950Y reversible vibratory plate, RD15 tandem roller, and D4000 diesel power unit. As a genuine OEM component, part 13507 is manufactured to the exact specifications Wacker Neuson requires for proper assembly and torque integrity across these machine families. Whether you're restoring a BS52Y rammer to full working order or servicing a DS720 diesel rammer, this stud bolt delivers the correct thread form, material grade, and dimensional accuracy the application demands. Confirm your model number before ordering to ensure a direct match from this broad fitment range.
Key Features
- Genuine OEM Material Grade — Manufactured to Wacker Neuson's specified tensile and thread standards, ensuring the bolt maintains clamping force under the high-cycle vibration loads typical of rammer and compactor operation.
- Exact Thread Form and Dimensions — Dimensionally identical to the original, so it threads into existing bores and mates with corresponding nuts without rework or shimming.
- Broad Fitment Across Rammer and Compactor Families — Compatible with BS30, BS45Y, BS45YA, BS52Y, BS60Y, BS65Y, and DS720 rammers, DPS1850Y and DPU2950Y vibratory plates, the RD15 tandem roller, and the D4000 diesel power unit.
- Vibration-Resistant Clamping Integrity — A correctly installed stud bolt keeps critical assemblies torqued and aligned; a worn or damaged stud can allow joint loosening, accelerating wear on surrounding components.
- Direct OEM Source — Sourced directly from Wacker Neuson's genuine parts program, so part number 13507 matches current production tolerances and quality controls.
A stud bolt is a fully threaded fastener used to clamp two or more components together within a machine assembly. Unlike a standard cap screw, a stud bolt threads permanently into one component at one end while a nut is applied at the other, providing a stable, repeatable clamping point that resists loosening under continuous vibration. In rammers and compactors — machines that operate under intense, repetitive shock loads — maintaining correct fastener torque is critical to keeping housings, covers, and structural components properly aligned. When a stud bolt stretches, strips, or corrodes, joint integrity is compromised, which can lead to misalignment, accelerated wear on adjacent parts, and potential structural failure if left unaddressed.
Part Details
| Part Number | 13507 |
|---|---|
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Stud Bolt |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Diesel Vibratory Rammer, 330mm /13in Shoe | DS720 | 5000008203 |
| Vibratory Rammer with 254mm/10 in Shoe | BS52Y | 5000007508, 5000008053, 5000008054, 5000009409, 5000007148, 5000007559, 5000007560, 5000007609 |
| Variable Speed Vibratory Ramme r, 280mm/11in Shoe | BS65Y | 5000007567, 5000007566 |
| Hydrostatic Double Drum Vibrat ory Roller | RD15 | 5000008057 |
| BS30 | BS30 | 5000005216 |
| Diesel Power Unit for Internal Vibrator | D4000 | 5000009091 |
| Vibratory Rammer | BS60Y | 5000006779, 5000007509 |
| Vibratory Rammer with 250mm/10 in Shoe | BS45Y | 5000007137 |
| Vibratory Rammer with 152mm/6i n Shoe | BS45YA | 5000007558 |
| Vibration Plate DPS 1850Y | DPS1850Y | 5000007780 |
| Reversible Vibratory Plate, 29 kN, 50cm/20in | DPU 2950Y | 5000007874 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
