The Genie 110789GT is a genuine OEM Shim Washer,.0151 THK, designed for Genie S series telescopic boom lifts, SX series super-boom lifts, and Z series articulating boom lifts. As a factory-sourced component, this shim washer delivers the exact thickness tolerance required for proper mechanical alignment and clearance in the assemblies it supports. Cross-reference part number 110789GT against your machine's parts manual to confirm fitment before ordering. This part covers an extensive range of Genie booms, including popular models such as the S-60 XC, S-85, S-125, SX-180, Z-45/25J Bi-Energy, and Z-135/70.
Key Features
- Exact Thickness Specification — Manufactured to the precise .0151 THK dimension, ensuring correct mechanical clearance and alignment in the boom assembly without guesswork or shimming adjustments.
- Genuine OEM Sourcing — Produced to Genie's original design requirements, so this shim washer matches the material grade and dimensional tolerances of the part it replaces.
- Direct Drop-In Replacement — Installs in the same position as the original with no reworking of mating components, keeping service time to a minimum.
- Broad Boom Lift Coverage — Fits Genie S and SX series telescopic boom lifts and Z series articulating boom lifts across a wide range of configurations, including IC Power, DC, Bi-Energy, FE Hybrid, TRAX, HC, and XC variants.
- Protects Critical Tolerances — A correctly fitted shim washer prevents unwanted play or binding in pivoting and rotating joints, helping the boom structure move and load as designed.
- Aerial-Lift Safety Integrity — On boom lifts, improper joint clearances caused by a missing or worn shim washer can affect structural load paths and boom stability — using the correct OEM-spec replacement is a genuine safety consideration.
A shim washer is a precision-thickness spacer used to set and maintain exact clearances between mating mechanical components — typically at pivot pins, joint assemblies, or rotating connections within a boom structure. On Genie telescopic and articulating boom lifts, these clearances are critical: too much play and the joint can develop slop that accelerates wear on surrounding hardware; too little and friction or binding can impede movement and place stress on structural members. When a shim washer wears thin, deforms, or is lost during service, the affected joint loses its calibrated fit, which can lead to abnormal wear, noise, and — in a working aerial lift — compromised structural integrity at height.
Part Details
| Part Number | 110789GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Shim Washer, .0151 THK |
Compatibility & Fitment
| Name | Model |
|---|---|
| S-80X | S-80X |
| S-80 | S-80 |
| S-85 | S-85 |
| S-60 | S-60 |
| S-65 | S-65 |
| S-60X | S-60X |
| S-60 XC | S-60 XC |
| S-60 HC | S-60 HC |
| S-60 TRAX | S-60 TRAX |
| S-65 TRAX | S-65 TRAX |
| S-100HD | S-100HD |
| S-120HD | S-120HD |
| SX-150 | SX-150 |
| SX-180 | SX-180 |
| S-40 | S-40 |
| S-45 | S-45 |
| S-3800 | S-3800 |
| S-3200 | S-3200 |
| S-120 | S-120 |
| S-125 | S-125 |
| S-100 | S-100 |
| S-105 | S-105 |
| Z-60/34 | Z-60/34 |
| Z-34/22 N | Z-34/22 N |
| Z-34/22 DC | Z-34/22 DC |
| Z-34/22 Bi-Energy | Z-34/22 Bi-Energy |
| Z-135/70 | Z-135/70 |
| Z-51/30J | Z-51/30J |
| Z-45/25 | Z-45/25 |
| Z-45/25J IC Power | Z-45/25J IC Power |
| Z-45/25J DC | Z-45/25J DC |
| Z-45/25J Bi-Energy | Z-45/25J Bi-Energy |
| Z-40/23N | Z-40/23N |
| Z-40/23N RJ | Z-40/23N RJ |
| Z-62/40 | Z-62/40 |
| Z-30/20 N | Z-30/20 N |
| Z-30/20N RJ | Z-30/20N RJ |
| Z-80/60 | Z-80/60 |
| Z-34/22 IC | Z-34/22 IC |
| Z-60/37 DC | Z-60/37 DC |
| Z-60/37 FE Hybrid | Z-60/37 FE Hybrid |
| Z-45/25 IC | Z-45/25 IC |
| Z-60 DC | Z-60 DC |
| Z-60 FE Hybrid | Z-60 FE Hybrid |
| Z-60 FE | Z-60 FE |
| Z-45/25J IC | Z-45/25J IC |
| ZX-135/70 | ZX-135/70 |
| Z-34 IC | Z-34 IC |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
