The Genie 61774-SGT is a genuine OEM Bellcrank Assembly Weldment designed for the Z-80/60 articulating boom lift. Sourced directly from Genie, this component meets the exact engineering standards of the original part and installs as a direct replacement with no adaptation required on compatible machines. Cross-reference part number 61774-SGT against your parts manual to confirm this is the correct assembly for your unit before ordering.
Key Features
- Genuine OEM Weldment Construction — Fabricated to Genie's original engineering tolerances, ensuring structural integrity and correct range of motion for the bellcrank mechanism.
- Direct Service Replacement — This assembly is designed to drop into the existing pivot and linkage mounting points on the Z-80/60, preserving the original geometry of the boom's articulation system.
- Confirmed Fitment for the Z-80/60 — Engineered specifically for the Z-80/60 articulating boom lift — always verify against your serial number and parts manual before installation.
- Maintains Correct Boom Articulation — A sound bellcrank weldment transfers motion accurately between linkage components; a cracked or worn weldment introduces slop and unpredictability into boom movement.
- Structural Safety in an Aerial Application — As a load-bearing pivot component in a boom lift's articulation system, this weldment's structural condition directly affects safe and controlled platform positioning.
The bellcrank is a pivoting lever that redirects and transfers mechanical force between two or more linkage rods or cylinders within the boom's articulation system. On an articulating boom like the Z-80/60, the bellcrank weldment plays a critical role in translating hydraulic cylinder movement into smooth, controlled boom joint rotation. When this component cracks, bends, or develops wear at its pivot points, the articulation system loses precision — resulting in sluggish or inconsistent boom response and potential loss of controlled movement at height.
Part Details
| Part Number | 61774-SGT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Bellcrank Assembly Weldment, SRV |
Compatibility & Fitment
| Name | Model |
|---|---|
| Z-80/60 | Z-80/60 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
