The Genie 76751GT is a genuine OEM LH Drive Pivot Weldment designed for TZ-50/30 and TZ-50 trailer-mounted articulating boom lifts. As a factory-sourced component, this weldment matches the original engineering specifications of the drive assembly, ensuring a direct, bolt-in installation without adaptation. Sourced directly through authorized Genie OEM supply channels, it is the correct replacement when the left-hand drive pivot shows wear, cracking, or structural fatigue. Cross-reference part number 76751GT against your machine's parts manual to confirm fitment before ordering.
Key Features
- Genuine OEM Structural Integrity — Manufactured to the same weld and material standards as the original component, ensuring the pivot point maintains its load-bearing capability under articulating boom operation.
- Direct Bolt-In Replacement — Engineered to match original mounting points and geometry on the drive assembly, allowing straightforward installation on the left-hand side of the drive system.
- Confirmed Fitment for TZ Trailer Booms — Designed specifically for the TZ-50/30 and TZ-50 trailer-mounted articulating boom lifts, keeping replacement sourcing straightforward for these models.
- Maintains Drive System Alignment — A correctly fitted pivot weldment holds the drive components in proper alignment, supporting smooth and consistent machine movement during operation.
- Safety-Critical Structural Component — The drive pivot weldment is a load-bearing element of the boom's drive system. A failed or cracked weldment can compromise machine mobility and structural control — replacing it promptly is essential for safe operation of aerial equipment.
The drive pivot weldment is a structural welded assembly that forms the left-hand pivot point within the drive system of the boom lift. It allows controlled articulation and movement of drive components as the machine operates, absorbing stress and maintaining correct positional geometry under load. When this weldment cracks, distorts, or becomes worn, drive function is compromised and the machine may lose the precise control needed for safe aerial positioning — making timely replacement with a correct OEM part essential.
Part Details
| Part Number | 76751GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | LH Drive Pivot Weldment |
Compatibility & Fitment
| Name | Model |
|---|---|
| TZ-50/30 | TZ-50/30 |
| TZ-50 | TZ-50 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
