The Genie 1283533GT is a genuine OEM Rear Axle Weldment designed for a wide range of Genie telescopic and articulating boom lifts, including the S-60, S-65, and Z-62/40 series. As a factory-original structural component, this weldment meets the exact engineering specifications of the machines it serves, ensuring a direct, confidence-inspiring replacement. Compatible models include the S-60, S-60 XC, S-60 HC, S-60 HF, S-60 TRAX, S-65, S-65 XC, S-65 HF, S-65 TRAX, and Z-62/40 — cross-reference part number 1283533GT against your parts manual to confirm fitment for your specific unit. Sourcing a genuine OEM part means no guesswork about material grade, weld geometry, or mounting dimensions.
Key Features
- Factory-Original Structural Integrity — Manufactured to Genie OEM standards, this weldment matches the precise geometry, steel grade, and weld specifications of the original component — critical for a load-bearing axle assembly.
- Direct Bolt-In Replacement — Engineered to align with existing mounting points and axle hardware on compatible boom lifts, supporting a straightforward swap without custom fabrication or fitment adjustments.
- Broad Boom Lift Compatibility — Fits multiple S-series telescopic boom variants (including XC, HC, HF, and TRAX configurations) as well as the Z-62/40 articulating boom, covering a wide slice of Genie's full-size boom fleet.
- Maintains Drive Alignment and Load Transfer — A sound rear axle weldment keeps the drive and steering geometry true, ensuring stable tracking, even tire wear, and correct weight distribution under load on the boom platform.
- Structural Safety at Height — On boom lifts operating at significant working heights, rear axle integrity is directly tied to machine stability and safe travel. Replacing a cracked or compromised weldment restores the structural baseline the machine's stability calculations depend on.
The rear axle weldment is the primary structural backbone of the boom lift's rear axle assembly, connecting the axle components to the machine's chassis and transferring drive forces, steering inputs, and load stresses between the wheels and the frame. Because it is a welded — rather than bolted — structure, it must maintain its shape and strength under repeated dynamic loading; a cracked, bent, or corroded weldment compromises chassis alignment and can affect steering response and overall machine stability. When this component shows signs of fatigue or damage, replacing it with a genuine OEM part like the part is the most direct way to restore the structural integrity the machine was designed with.
Part Details
| Part Number | 1283533GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Rear Axle Weldment |
Compatibility & Fitment
| Name | Model |
|---|---|
| S-60 | S-60 |
| S-65 | S-65 |
| S-60X | S-60X |
| S-60 XC | S-60 XC |
| S-60 HC | S-60 HC |
| S-60 TRAX | S-60 TRAX |
| S-65 TRAX | S-65 TRAX |
| S-65 XC | S-65 XC |
| S-60 HF | S-60 HF |
| S-65 HF | S-65 HF |
| Z-62/40 | Z-62/40 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
