The Genie 116770GT is a genuine OEM AC Wire Harness with Switches, 60Hz, 1-240V & 1-GFI, designed for Genie AL5000, AL5 with Vertical Mast, and AL5 portable light towers. As a direct OEM replacement, this harness is manufactured to the same electrical specifications as the original, ensuring correct conductor routing, connector compatibility, and proper integration with the unit's 240V and GFI switch circuits. Cross-reference part number 116770GT against your parts manual to confirm fitment before ordering.
Key Features
- Correct Electrical Specification — Built to the original 60Hz, 1-240V and 1-GFI circuit configuration, ensuring the harness matches the light tower's power distribution layout precisely.
- Genuine OEM Construction — Sourced directly from Genie, this harness uses the same wire gauges, connector housings, and switch interfaces as the factory-installed unit — no re-pinning or adapter work required.
- Confirmed Fitment — Compatible with AL5000, AL5 with Vertical Mast, and AL5 light towers; verify using part number 116770GT in your Genie parts manual.
- Maintains GFI Circuit Integrity — A correctly functioning AC harness ensures the GFI outlet circuit operates as intended, protecting both equipment and personnel from ground-fault conditions.
- Supports Safe Electrical Operation — On a light tower, the AC distribution harness carries mains-level voltage to the outlets and switches; using a genuine replacement preserves the insulation ratings and connector seating critical for safe field operation.
The AC wire harness in a Genie light tower routes mains-level alternating current from the generator output to the unit's 240V receptacle and GFI-protected outlet, connecting through the integrated switches that allow the operator to control power distribution. It acts as the central electrical backbone for the tower's output circuits — if the harness degrades, develops a short, or suffers connector failure, the affected outlets will lose power or the GFI may trip unexpectedly, leaving the jobsite without light or auxiliary power. Replacing a damaged harness with a genuine OEM part restores the correct current path and ensures all switching and ground-fault protection functions work as originally designed.
Part Details
| Part Number | 116770GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | AC Wire Harness with Switches, 60Hz, 1-240V & 1-GFI |
Compatibility & Fitment
| Name | Model |
|---|---|
| AL5000 | AL5000 |
| AL5 with Vertical Mast | AL5 with Vertical Mast |
| AL5 | AL5 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
