Multiquip H1010PB Cylinder 10 Ton 10 Inch Stroke

The Multiquip H1010PB Cylinder 10 Ton 10 Inch Stroke is a genuine OEM hydraulic cylinder designed for Multiquip rebar bender models JB5135, JB5090, JB7090, JB8090, JB9180, JB11090, JB7135, and JPU1. As a direct OEM replacement, the part is manufactured to the exact specifications of the original component, ensuring proper fit and full hydraulic output for your bending equipment. Sourced directly through Multiquip's authorized parts network, this cylinder is the correct service replacement when your existing unit shows signs of leaking, loss of pressure, or reduced stroke travel.

Key Features

• Rated Hydraulic Output: — Engineered to deliver a full 10-ton force capacity with a 10-inch stroke length, matching the original cylinder's working load specification exactly.
• Genuine OEM Construction: — Built to Multiquip's original hydraulic cylinder tolerances, including bore diameter and seal groove geometry, so internal pressure ratings are preserved after installation.
• Broad Rebar Bender Compatibility: — Confirmed fitment across JB5135, JB5090, JB7090, JB8090, JB9180, JB11090, JB7135, and JPU1 rebar bender models.
• Direct Bolt-In Replacement: — Matches the original mounting configuration and hydraulic port locations, allowing the cylinder to swap into the existing bender frame without machining or adaptation.
• Restores Full Bending Force: — A worn or leaking cylinder causes incomplete bends, inconsistent bend angles, and hydraulic pressure loss; replacing with the correct OEM cylinder restores rated performance.
• Pressure System Integrity: — Correct seal material and cylinder wall specification prevent internal bypass, protecting the hydraulic pump and control valve from overload caused by a failing cylinder.

The hydraulic cylinder is the core force-generating component in a rebar bender. When the hydraulic pump pressurizes the cylinder, the piston extends through its stroke, driving the bending arm to shape steel reinforcing bar to the specified angle. The 10-ton rating indicates the maximum linear force the cylinder can sustain, while the 10-inch stroke defines how far the piston travels — both values must match the original specification for the bender to reach its full range of bend angles accurately. When a cylinder develops internal seal wear or external damage, hydraulic fluid bypasses the piston, reducing available force and causing sluggish or incomplete bends that compromise rebar placement quality on the jobsite.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
