Multiquip HP0505PB Cylinder 5 Ton 5-1/2 In. Stroke

The Multiquip HP0505PB Cylinder 5 Ton 5-1/2 In. Stroke is a genuine OEM hydraulic cylinder designed for Multiquip rebar bender models JB5135, JB7135, JB7090, JB9180, JB11090, JPU1, JB5090, and JB8090. As a factory-sourced component, HP0505PB matches the original cylinder's rated tonnage and stroke length exactly, ensuring the bender delivers full bending force without calibration adjustments. Sourced directly through Multiquip's OEM supply chain, this cylinder is the correct service replacement when the original shows signs of seal failure, pressure loss, or physical damage. DHS Equipment stocks this part to keep your rebar bending operation running at full capacity.

Key Features

• Rated 5-Ton Hydraulic Output — delivers the full clamping and bending force required for consistent, clean rebar bends across all compatible JB-series benders.
• 5-1/2 In. Stroke Specification — matches the original stroke length precisely so the bending arm completes its full arc without adjustment or shimming.
• Genuine OEM Component — manufactured to Multiquip's original hydraulic cylinder specification, including bore diameter, port sizing, and seal material grade.
• Broad JB-Series Fitment — confirmed for JB5090, JB5135, JB7090, JB7135, JB8090, JB9180, JB11090, and JPU1 rebar benders.
• Drop-In Service Replacement — retains the same mounting interface and hydraulic port configuration as the original, so the cylinder swaps in using standard hand tools.
• Restores Full Bending Capacity — a worn or leaking cylinder causes incomplete bends and pressure drop; replacing with HP0505PB brings output back to rated performance.

The hydraulic cylinder is the core actuator in a rebar bender — it converts hydraulic pressure from the power unit into the linear force that drives the bending pin through its arc. When the cylinder is functioning correctly, the machine delivers consistent, repeatable bends at the rated tonnage across the full range of rebar sizes the bender is designed to handle. When the cylinder seals degrade or the bore is damaged, pressure escapes internally, the bending force drops off, and bends become incomplete or inconsistent — stalling production and placing additional stress on the hydraulic circuit. Replacing the cylinder with the correct OEM unit restores the hydraulic system to its original pressure and stroke specification.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
