The Wacker Neuson Armature is a genuine OEM component designed for the AR 3/2 series external concrete vibrators, including AR 3/2 S, AR 3/2 W, and AR 3/2 W/S models across multiple voltage and frequency configurations. As a direct OEM replacement, the is manufactured to the same specifications as the original part, ensuring correct electrical performance and mechanical fit within the motor assembly. This armature covers an extensive range of AR 3/2 variants, from standard 400V and 460V units through to 230/460V 60Hz configurations, making it the go-to replacement for operators running multiple AR 3/2 machines on site.
Key Features
- Correct Winding Specification: — Genuine OEM windings matched to the original voltage and frequency ratings of AR 3/2 S, AR 3/2 W, and AR 3/2 W/S external vibrators, delivering the precise rotational output the motor was designed for.
- Drop-In Motor Replacement: — Engineered to the same shaft dimensions and lamination stack as the original, allowing straightforward installation into the existing motor housing without modification.
- Broad AR 3/2 Series Coverage: — Confirmed fitment across AR 3/2 S, AR 3/2 W, AR 3/2 W/S, and AR 3/2 460V 60Hz variants, spanning a wide range of machine numbers within the AR 3/2 family.
- Restored Vibration Output: — A worn or shorted armature causes loss of motor torque and inconsistent vibration frequency; replacing with this OEM part restores full eccentric-weight rotation and consistent concrete consolidation performance.
- Electrical Safety Compliance: — External vibrators operate in wet concrete environments where motor integrity is critical; using a genuine OEM armature maintains the insulation class and electrical safety integrity of the original design.
The armature is the rotating core of the electric motor inside an external concrete vibrator. It carries the wound copper coils that interact with the stator's magnetic field to generate rotation, which in turn drives the eccentric weight responsible for producing the vibration force applied to formwork or molds. When an armature wears out or suffers winding failure — often from overheating, moisture ingress, or age — the motor loses torque, runs erratically, or stops altogether, halting concrete consolidation work until the component is replaced. Fitting a correct-specification armature like the 5000063229 restores full motor output and keeps the vibrator performing as intended.
Part Details
| Part Number | 5000063229 |
|---|---|
| Old Part Number | 0063229 |
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Armature |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| External Vibrator, 3000 rpm, 4 00V | AR 3/2 | 5000006119 |
| External Vibrator AR 3/2 W | AR 3/2 W | 5000006120 |
| AR3/2 460V,3 EXTERNAL VIBRATOR | AR 3/2 S | 5000006348, 5000006351, 5000006423, 5000006479, 5000006493, 5000006662, 5000006708, 5000006830, 5000006950, 5000007296, 5000007769 |
| External Vibrator AR 3/2 W/S | AR 3/2 W/S | 5000006366, 5000006429, 5000006430, 5000006494 |
| External Vibrator 230/460 V | AR 3/2 460V 60Hz | 5000008960 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
