The Wacker Neuson Rear Frame is a genuine OEM structural component designed for the RD16-90 and RD16-100 series tandem vibratory rollers. Sourced directly from Wacker Neuson, this part matches the original frame specification used across the RD16 roller family, including Hydrostatic and standard configurations. Whether you are rebuilding after impact damage or restoring a roller to full working order, the delivers the structural integrity these machines demand. Confirmed fitment spans the RD16-90 Tandem Roller, RD16-90 Hydrostatic Vibratory Roller, and RD16-100 variants.
Key Features
- OEM Structural Specification: — Manufactured to the exact geometry and material grade of the original rear frame, ensuring all mounting points, articulation interfaces, and component attachment positions align correctly.
- Direct Bolt-In Replacement: — Engineered as a drop-in replacement for the RD16-90 and RD16-100, with all weld brackets, bore locations, and fastener patterns matching the original assembly.
- Broad RD16 Family Coverage: — Fits RD16-90 standard and Hydrostatic configurations, as well as RD16-100 standard and Hydrostatic models, covering a wide range of RD16 series serial ranges.
- Restores Full Load-Bearing Integrity: — A compromised rear frame can cause misalignment between the drum, drive system, and articulation joint; replacing it with a correct OEM part restores the machine's operational geometry and weight distribution.
- Articulation Safety Compliance: — The rear frame is a load-bearing structural member that houses the articulation pivot; using a genuine OEM replacement ensures the joint meets original design tolerances, critical for safe steering and stability on grade.
The rear frame is the primary structural backbone of the rear half of a tandem vibratory roller, carrying the rear drum assembly, drive components, operator platform mounts, and the articulation joint that links the rear to the front frame. On machines like the RD16-90 and RD16-100, the rear frame must maintain precise alignment under continuous vibration and the stresses of articulated steering across uneven asphalt and soil surfaces. When the rear frame is cracked, bent, or damaged at mounting points, it can cause drum misalignment, irregular compaction patterns, drivetrain stress, and unsafe handling — making prompt replacement essential to keeping the roller compacting accurately and operating safely.
Part Details
| Part Number | 5000161706 |
|---|---|
| Old Part Number | 0161706 |
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Rear Frame |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| RD16-90 Vibratory Roller | RD16-90 | 5000620060, 5000620127, 5000620799 |
| RD 16-100 | RD16-100 | 5000620402, 5000620798 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
